Apr 22, 2018 67 Responses to Installing High Sierra 10.13.4 in VirtualBox 5.x. Supratim Sanyal says: April 28, 2018 at 1:35 am. Worked perfectly, thanks. On Windows 10 host using. Jan 15, 2020 To install the High Sierra version on Windows 10 using Oracle VM VBox, follow the stages below in order. Apple today (June 1, 2018) released the 10.13.5/6 version of Mac OS High Sierra. The installation of Mac OS 10.13.5 in VBox is the same as the following stages. Open the Oracle VM VBox program and click the New button to create a new. Welcome, here I will show you to Download macOS High Sierra for VMware & VirtualBox Image. Therefore, if you want to install or test any operating system on your computer you need the latest version of that operating system. MacOS High Sierra is the fourteenth major release of macOS or Apple company, Typically you can install macOS High Sierra on Macintosh as an operating system, macOS High.

MacOS VirtualBox VM on Ubuntu

Posted by Shujin Wu on February 23, 2017

Step 1： Download the Sierra installer from Mac App Store.

This should be done in you Mac and the installer will be placed in /Application/ folder.

Step 2: Prepare Sierra iso

Use geerlingguy’s script to prepare a sierra iso file.

Step3: Install VirtualBox in Ubuntu

You should have your VirtualBox and the Extension Pack installed, or use my ansible role

Step 4: Open VirtualBox and create a new VM.

Settings:

• name: your_sierra_vm_name
• type: Osx
• version: Mac OS X 10.11 El Capitan (64-bit)
• Other

Step5: Configure VM for MacOS (Very important!)

Run following commands and replace “Sierra” with ‘your_sierra_vm_name’.

Step 6: Install Sierra

Insert sierra.iso to the sierra VM’s optical driver, and follow the instruction to install Sierra.

Note: In the installer, Go to Utilities > Disk Utility. Select the VirtualBox disk and choose Erase to format it as a Mac OS Extended (Journaled) drive.

Step 7: Remove sierra.iso and restart VM.

Reference

See also:

During a recent pentest, I needed to throw together a macOS virtual machine. Although there was lots of guides around the web, none seemed to work from start to finish. This post contains the steps I extracted from various resources in order to get a fully working High Sierra install within VirtualBox 5.

Step 1: Download The High Sierra Installer

To do this, you need to be on an existing macOS system. I was unable to find the download within the App Store itself, but following this link opened the App Store at the correct page: https://itunes.apple.com/us/app/macos-high-sierra/id1246284741?mt=12

After opening the aforementioned page in the App Store, start the download, but cancel the installation when it starts.

You can then verify that the installer has been downloaded by checking that '/Applications/Install macOS High Sierra.app' exists.

Step 2: Create a Bootable ISO

Next, you need to create an ISO from the installer application that was downloaded in step 1.

Running the below commands will create an ISO on your desktop named HighSierra.iso:

Step 3: Creating the Virtual Machine

I experimented with a few different settings in regards to the CPU and RAM allocation. I didn’t find a combination that didn’t work, but create a VM with the following things in mind:

• Ensure the name of the VM is MacOS (ensure to keep the same casing)
• Ensure the type is Mac OS X and the version is macOS 10.12 Sierra (64-bit) (there is a High Sierra option too, but I chose Sierra by accident and it worked)
• Untick Floppy in System > Motherboard > Boot Order
• Use >= 4096 MB of memory in System > Motherboard
• Use >= 2 CPUs in System > Processor
• Use 128 MB of video memory in Display > Screen
• Optionally enable 3D acceleration in Display > Screen
• Remove the IDE device in Storage > Storage Devices and replace it with a SATA controller
• Add a new hard disk device under the SATA controller with >= 60 GB of space
• Ensure an optical drive is present under the SATA controller and mount the previously created ISO to it
• Untick the Enable Audio option under Audio

After creating the virtual machine with the above configuration, hit OK and exit the settings screen. Now, a number of extra options need to be set.

If you’re on Windows, you’ll need to cd into the appropriate directory under the VirtualBox installation path to run VBoxManage. For Linux users, this should be in your PATH variable already:

After running the above commands, the VM should be ready to boot!

Step 4: Installation

This is where near enough everything I read stopped, despite there being one more problem in the way - UEFI.

Boot into the VM, go into Disk Utility and erase the virtual disk that you added to the machine.

After erasing the disk, start the installation procedure. After a short amount of time, it will reboot the VM.

Downgrade From High Sierra To Sierra

Once it reboots, it’s going to boot back off the ISO again, once it’s done this, just shutdown the VM and eject the disk [the ISO] and then start the VM again to boot from disk.

On the next boot, it should boot into the installer that was copied to disk, but instead, you will be presented with a UEFI shell like below:

To continue the macOS installation, follow these steps:

1. Type exit and hit return
2. Select Boot Maintenance Manager and hit return
3. Select Boot From File and hit return
4. You will see two partitions, select the second partition and hit return
5. Select macOS Install Data and hit return
6. Select Locked Files and hit return
7. Select Boot Files and hit return
8. Select boot.efi and hit return

After following these steps, you will boot into the remainder of the macOS installation. From here, just follow the steps as per a regular macOS installation.

The next time you boot your virtual machine, you will not have to go through the UEFI shell; it should work without any further problems.

Step 5: Tweaking The Resolution

As there is no VirtualBox additions for macOS, the screen resolution won’t automatically change. If you know what resolution you wish to use, however, you can set it manually.

Install High Sierra On Virtualbox

Ensure the virtual machine is powered off, and then run the following command; replacing 1920x1080 with whatever resolution you would like to use:

After running the above command, the next time you boot the machine, it will use the resolution specified.

Install High Sierra Virtualbox For Windows

Now, you should have a fully working macOS virtual machine!

References

How To Install High Sierra Virtualbox

The information found in this post was pieced together from the following sources:
